True Pitch-Shift Vibrato with Classic and Expanded Waza Craft Modes
The Boss VB-2W Waza Craft is an all-analogue vibrato pedal that recreates the pitch-shifting movement of the original VB-2 while adding a new Custom mode. Standard mode delivers the vintage VB-2 sound, while Custom mode introduces a different vibrato character built around a unique filter wave for players who want to push the effect further.
Its BBD, or Bucket Brigade Delay, circuit creates the vibrato by passing the signal through a chain of analogue delay stages and modulating its pitch. Rate and Depth set the speed and intensity, while Rise Time controls how quickly the vibrato fades in after activation. An optional expression pedal can also control Depth in real time.
Latch gives you conventional on/off operation, while Unlatch keeps the effect active only while you hold the pedal down, making it easy to add vibrato to individual notes or chords. Bypass mode removes the BBD section from the signal path when the effect is off to avoid its inherent delay. The pedal is made in Japan and uses buffered bypass.
At Riffs & Licks Music, we think this analogue vibrato pedal is especially useful for players who want genuine pitch modulation rather than chorus-style movement, with enough control to move from subtle texture to more dramatic, expressive bends.
Features / Specifications
| Feature | Specification |
|---|---|
| Features | Waza Craft Innovation for a Premium Analogue Tone Experience Custom Mode with New Vibrato Sound and Unique Filter Wave Standard Mode Reproduces the Vintage VB-2 Vibrato Sound All-Analogue Circuit with BBD (Bucket Brigade) Vibrato Line Real-Time Effect Depth Control with Optional Expression Pedal Rise Time Control for the Initial Onset of the Vibrato Effect Unlatch Mode Activates the Effect Only While Pressing the Pedal Bypass Mode Removes the BBD from the Signal Path When the Effect Is Off Made in Japan |
| Modes | 3: Latch, Unlatch, Bypass |
| Nominal Input Level | -20 dBu |
| Input Impedance | 1 MΩ |
| Nominal Output Level | -20 dBu |
| Output Impedance | 1 kΩ |
| Recommended Load Impedance | 10 kΩ or Greater |
| Bypass | Buffered Bypass |
| Controls | Pedal Switch Standard/Custom Switch Rate Knob Depth Knob Rise Time Knob Mode Knob |
| Indicator | Check Indicator (Serves Also as Battery Check Indicator) |
| Connectors | Input Jack Output Jack Depth Jack DC In Jack |
| Power Supply | Alkaline Battery (9 V, 6LR61) or Carbon-Zinc Battery (9 V, 6F22) |
| Current Draw | 35 mA |
| Expected Battery Life | Alkaline: Approx. 22 Hours Carbon-Zinc: Approx. 4 Hours Figures Vary Depending on Actual Conditions of Use |
| Accessories (Included) | Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTE," and "Information"), Alkaline Battery (9 V, 6LR61) |
| Accessories (Optional) | AC Adaptor (PSA Series), Expression Pedal (FV-500H, FV-500L, Roland EV-5) |
| Width | 73 mm (2-7/8") |
| Depth | 129 mm (5-1/8") |
| Height | 59 mm (2-3/8") |
| Weight | 450 g (1 lb), Including Battery |
(VB2W)
- SPECIFICATIONS
- Modes
- 3 modes
LATCH
UNLATCH
BYPASS - Nominal Input Level
- -20 dBu
- Input Impedance
- 1 M ohm
- Nominal Output Level
- -20 dBu
- Output Impedance
- 1 k ohm
- Recommended Load Impedance
- 10 k ohms or greater
- Bypass
- Buffered bypass
- Controls
- Pedal switch
Standard/Custom switch
RATE knob
DEPTH knob
RISE TIME knob
MODE knob - Indicator
- CHECK indicator (Serves also as battery check indicator)
- Connectors
- INPUT jack
OUTPUT jack
DEPTH jack
DC IN jack - Power Supply
- Alkaline battery (9V, 6LR61) or Carbon-zinc battery (9V, 6F22)
AC adaptor (sold separately) - Current Draw
- 35 mA
- Expected battery life under continuous use (These figures will vary depending on the actual conditions of use.)
- Alkaline: Approx. 22 hours
Carbon: Approx. 4 hours - Accessories
- Owner's Manual
Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTE," and "Information")
Alkaline battery (9V, 6LR61) - Options (sold separately)
- AC adaptor: PSA series
Expression Pedal: FV-500H, FV-500L, Roland EV-5 - SIZE AND WEIGHT
- Width
- 73 mm
2-7/8 inches - Depth
- 129 mm
5-1/8 inches - Height
- 59 mm
2-3/8 inches - Weight (including battery)
- 450 g
1 lb
| SKU | VB2W |
| Barcode # | 4957054510442 |
| Brand | BOSS |
| Category |
