Electro-Harmonix Intelligent Harmony Machine Digital Harmoniser / Pitch Shifter Pedal
Perfect Harmonies at the Tap of a Footswitch
The Electro-Harmonix Intelligent Harmony Machine Digital Harmoniser / Pitch Shifter Pedal creates flawless, real-time harmonies that transform your single-guitar performance into a full ensemble. Choose from diatonic harmonies across all 12 keys or polyphonic pitch shifts that track chords and single notes with exceptional precision. With eleven harmony intervals, from subtle thirds to dramatic octave jumps, plus dual- and triple-harmony options, it offers a vast palette of creative possibilities. Momentary Mode allows expressive sweeps or instant pitch shifts, while the Mix control blends your dry and shifted tones seamlessly. Compact, versatile, and musical, it’s ideal for crafting layered solos or adding rich textures live or in the studio.
At Riffs & Licks Music, we think the Electro-Harmonix Intelligent Harmony Machine is the ultimate compact harmoniser for players seeking pro-level tracking and expressive tonal flexibility.
Features/Specifications
| Feature | Specification |
|---|---|
| Circuit | Digital |
| Bypass | Buffered Bypass |
| Audio | Mono |
| Power Supply | 9.6V DC 200mA power adaptor included (optional 9V battery not included) |
| Current Draw | 26 mA |
| Dimensions (W × D × H) | 114 × 70 × 53 mm (4.5" × 2.75" × 2.1") |
Harmony Options
| Mode | Interval Selection |
|---|---|
| 1 | 6th Down |
| 2 | Perfect 4th Down |
| 3 | 3rd Down |
| 4 | 3rd Up |
| 5 | Perfect 4th Up |
| 6 | Perfect 5th Up |
| 7 | 6th Up |
| 8 | 7th Up |
| 9 | 3rd Up + 5th Up Optional: 4th Down + 3rd Up / 6th Down + 4th Down |
| 10 | 3rd Up + 7th Up Optional: 3rd Up + 6th Up / 3rd Down + 3rd Up |
| 11 | Perfect 5th Up + Octave Up Optional: Octave Down + 5th Up / Octave Down + 4th Down |
Polyphonic Pitch Shift Intervals
| Mode | Interval Selection |
|---|---|
| 1 | Doubler |
| 2 | Perfect 4th Down |
| 3 | 3rd Down (minor or major) |
| 4 | 3rd Up (minor or major) |
| 5 | Perfect 4th Up |
| 6 | Perfect 5th Up |
| 7 | 2nd Down (minor or major) |
| 8 | 2nd Up (minor or major) |
| 9 | Octave Down |
| 10 | Octave Up |
| 11 | Perfect 5th Up + Octave Up |
(690INTELHARM)
| SKU | 690INTELHARM |
| Barcode # | 683274012377 |
| Brand | Electro Harmonix |
| Category |
