MAKE YOUR PLAYING SOAR WITH MAJESTIC AMBIENCE
Powered by Multi-Dimensional Processing technology (MDP), the TE-2 Tera Echo produces a dynamic new stereo ambience effect that goes far beyond traditional delay and reverb.

Next-generation BOSS compact pedal with innovative Multi-Dimensional Processing, realized with proprietary technology and custom DSP
Rich, spacious echo and ambience effects
Dramatically enhances the direct tone, but never overwhelms it
Freeze function holds the ambient sound for lead backing and sound effects
Ultra-responsive to volume changes and playing dynamics
Wide range of sound adjustment with simple controls
Mono/stereo input and output

(TE2)

Nominal Input Level: 20 dBu
Input Impedance: 1 M ohm
Nominal Output Level: 20 dBu
Output Impedance: 1 k ohm
Recommended Load Impedance: 10 k ohms or greater
Controls: Pedal switch
E. LEVEL knob
TONE knob
FEEDBACK knob
S-TIME (Spread Time) knob
Indicator: CHECK indicator (Used for indication of HOLD, and to check battery)
Connectors: INPUT-A (MONO) jack
INPUT-B jack
OUTPUT-A (MONO) jack
OUTPUT-B jack
AC adaptor jack (DC 9 V)
Power Supply: Alkaline battery (9V, 6LR61) or Carbon-zinc battery (9V, 6F22)
AC adaptor (sold separately)
Current Draw: 53 mA
* Expected battery life under continuous use
Alkaline:Approx. 6 hours
Carbon: Approx. 1.5 hours
These figures will vary depending on the actual conditions of use.
Accessories: Owner's Manual
Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTE," and "Information")
Alkaline battery (9V, 6LR61)
Option (sold separately): AC adaptor (PSA series)
SIZE AND WEIGHT (INCLUDING BATTERY )
Width: 73 mm
2-7/8 inches
Depth: 129 mm
5-1/8 inches
Height: 59 mm
2-3/8 inches
Weight: 435 g
0 lbs. 16 oz.
