Boss AD2 Acoustic Preamp Pedal with DI

NATURAL ACOUSTIC SOUND EVERYWHERE YOU PLAY

With the AD-2 Acoustic Preamp, acoustic-electric guitarists can now experience natural, studio-quality sound while performing on any stage. Equipped with an advanced BOSS sound engine, this compact pedal packs sophisticated processing power that belies its small size and simple, intuitive interface. Acoustic Resonance reproduces the complex resonance characteristics of your unplugged tone, while Ambience provides pro-level reverberation perfectly optimized for acoustic guitar. The AD-2 also features essential stage tools such as a notch filter for feedback control, a balanced DI out for direct connection to a PA, and a convenient mute function for tuning and switching guitars.

Acoustic-electric guitar preamp with advanced BOSS sound processing
Sophisticated under-the-hood processing with multiple interlocked parameters, accessible with simple stompbox controls
Acoustic Resonance reproduces the complex resonance characteristics of an unplugged acoustic
Ambience knob provides wide-ranging, studio-quality reverb optimized for acoustic guitar
Notch filter for instant feedback reduction
Normal output for an acoustic guitar amp and balanced DI output for direct PA connection
Sound mute function for switching guitars and tuning on stage

(AD2)

SPECIFICATIONS
Nominal Input Level: -20 dBu
Input Impedance: 10 M ohms
Nominal Output Level: OUTPUT jack: -20 dBu
LINE OUT jack: -20 dBu
Output Impedance: OUTPUT jack: 1 k ohm
LINE OUT jack: 600 ohms
Recommended Load Impedance: OUTPUT jack: 10 k ohms or greater
LINE OUT jack: 600 ohms or greater
Bypass: Buffered bypass
Controls: Pedal switch
ACOUSTIC RESONANCE knob
AMBIENCE knob
NOTCH knob
Indicator: CHECK indicator (Serves also as battery check indicator)
Connectors: INPUT jack: 1/4-inch phone type
OUTPUT jack: 1/4-inch phone type
LINE OUT jack: 1/4-inch TRS phone type
DC IN jack
Power Supply: Alkaline battery (9V, 6LR61) or Carbon-zinc battery (9V, 6F22)
AC adaptor (sold separately)
Current Draw: 55 mA
Expected battery life under continuous use: Alkaline: Approx. 6 hours
* These figures will vary depending on the actual conditions of use.
Accessories: Owner's manual
Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information")
Alkaline battery (9V, 6LR61)
Option (sold separately): AC adaptor (PSA series)
SIZE AND WEIGHT
Width: 73 mm
2-7/8 inches
Depth: 129 mm
5-1/8 inches
Height: 59 mm
2-3/8 inches
Weight (including battery): 450 g
1 lb
