Baggs Voice Print DI Digital Acoustic Guitar IR Pedal
Make the most of your new gear with the below
Turn Your Pickup Signal into a Custom Voiceprint of Your Guitar
The Baggs Voiceprint DI uses custom impulse response processing to bring more of your guitar’s acoustic character back into its amplified sound. Using the AcousticLive app on a compatible iOS or Android phone, the system measures your guitar and pickup together to create a personalised Voiceprint, which can then be blended with the raw pickup signal to suit the way you want the instrument to respond live.
Up to 99 presets can be stored in the pedal, so once they are created you do not need your phone on stage. The Voice control adjusts the Voiceprint blend, while Anti-FB applies your feedback profile and also provides phase inversion. Pad settings of 0, -3, -6 or -9 dB help accommodate different pickup levels.
You also get Mute/Bypass and Next footswitches, Ground Lift, a series effects loop, 6.35 mm (1/4") input, plus XLR and 6.35 mm (1/4") outputs. The 9V 500 mA power supply is included.
At Riffs & Licks Music, we think this digital acoustic IR pedal is a great choice for players who want a personalised pickup sound, powerful feedback control and multiple guitar presets in one live-performance unit.
Features
| Main Features/Operation Modes | |
| Capture | Guided by LR Baggs' AcousticLive app and proprietary impulse response technology, you can now use your smartphone like a studio in your pocket to capture a Voiceprint of your acoustic guitar. Developed with Dr. Jonathan Abel, co-founder of Universal Audio, Voiceprint technology utilizes a sophisticated algorithm that intuitively measures your acoustic guitar by analyzing its actual timbre and playing response, then creates a customized preset for live play, as well as for direct recordings. Simply plug into the pedal and set your smartphone into position; tap on the bridge, strum a few chords, pick some strings, and you’re done! |
| Enhance | As an added benefit, every Voiceprint that you create identifies your guitar’s specific resonances that are prone to feedback and creates an Anti-FB profile to easily manage feedback with one simple control on the pedal. The app also provides advanced features, such as a graphical full-parametric EQ for balancing each preset to your exact taste. These features can also be used for creating enhanced presets, even if you choose not to apply a Voiceprint. |
| Connect | The AcousticLive app provides the processing you need to create your presets, while the Voiceprint DI is your live performance engine. With advanced processing at 96 kHz sampling, the robust playback algorithms provide studio quality performance designed for easy control during your live show. You can manage your presets in the app and store up to 99 instruments in your Voiceprint DI. The hardware is designed with a simple layout that includes the key features you will need for a successful show, but you can connect with the app during your live performance for additional functionality and control. |
| Additional Features | |
| Master Volume level control | |
| Voice blends your instrument’s custom Voiceprint with your pickup signal for enhanced accuracy | |
| Anti-fb applies your anti-feedback profile for effective feedback control. Short press for phase inversion | |
| Select scrolls through up to 99 instrument presets | |
| Pad attenuates input by 0dB, -3dB, -6dB, or -9dB to accommodate a wide-range of input levels | |
| Mute footswitch for ¼" and XLR outs. Long press for bypass | |
| Next footswitch selects the next instrument preset | |
| Series FX loop (separate jacks for send and return) | |
| Ground lift switch effectively eliminates ground-loop noise | |
| ¼" input | |
| XLR and ¼" outputs | |
| 9V DC power | |
| Compatible with iPhone 6 and later as well as with most major Android device manufacturers | |
Specifications
| Feature | Specification |
|---|---|
| Instrument | Any |
| Type | FX/Processing |
| Position | Floor, Pedalboard |
| Active/Passive | Active |
| Preamp | No |
| Processor | 96 kHz |
| Controls | Volume, Anti-FB, Voice, Select, Pad, Mute, Next, Ground/Lift |
| Power Source | 9V 500 mA Power Supply |
| Included | Voiceprint DI 9V power supply |
(LRBVOICEPRINTDI)
| SKU | LRBVOICEPRINTDI |
| Barcode # | 0897042002297 |
| Brand | Baggs |
| Category |
